AC Voltage Sensor Module ZMPT101B (Single Phase)

Description

1. ZMPT101B AC Voltage Sensor Module

   • Accurate AC Sensing: Measures single-phase AC voltage with reliable signal output.
   • Electrical Isolation: Uses a ZMPT101B transformer for safer voltage monitoring.
   • Analog Output: Provides a scaled analog signal for easy ADC/microcontroller interfacing.
   • Adjustable Output: Built-in adjustment allows convenient signal calibration.
   • Wide Compatibility: Suitable for 50Hz and 60Hz AC systems.
   • Compact Design: Small PCB module for easy integration into electronic projects.
   • Microcontroller Friendly: Works well with Arduino, ESP32, and other control boards.
   • Versatile Applications: Ideal for energy monitoring, automation, power measurement, and embedded systems.

   Specifications

   • Module Type: AC Voltage Sensor
   • Sensing Element: ZMPT101B Voltage Transformer
   • Measurement: Single-Phase AC
   • Output: Analog Voltage
   • Frequency: 50/60Hz
   • Isolation: Transformer-Based
   • Mounting: PCB Module
   • Use: AC Voltage & Power Monitoring

   Applications

   • AC voltage measurement
   • Energy and power monitoring
   • Arduino & ESP32 projects
   • Home automation systems
   • Inverter monitoring
   • Industrial control
   • Embedded monitoring systems
   • Electrical equipment testing
